@Stilling To improve rigidity, just finished attaching a new second spindle holder to my SainSmart Genmitsu 4030 ProxerXL CNC aluminum router. Also replaced my clogged MQL (Minimum Quantity Lubrication) sprayer with a new dual sprayer.

#cnc #aluminum #router #maker #cncrouter #cncaluminum #foss #fosh #genmitsu #sainsmart #proverxl #proverxl4030 #mql

A CNC machine with a focus on the cutting head and the workpiece. The cutting head is equipped with two adjustable blue coolant / lubrication hoses, which is coiled around the head. The aluminum workpiece, secured by blue clamps, features circular and rectangular cutouts. The machine is mounted on a metal frame with linear guides, allowing for precise movement along the X and Y axes. In the background, there are boxes. The setting appears to be a workshop or a manufacturing environment, with various tools and materials visible.

After tightening the spindle, moving it down a bit and trying to reduce cantilever by gripping the spindle as close to the tool as possible, this is a second pass with otherwise same parameters. This could all be considered rough pass, since I'm not doing any finish passes yet. Thanks @Stilling for the advice.

#cnc #aluminum #router #maker #cncrouter #cncaluminum #foss #fosh #genmitsu #seinsmart #proverxl #proverxl4030

A hand holding a metallic L-shaped object with a shiny silver finish. The object has four black circular components attached to its sides, likely for mounting or securing purposes. The background features a computer setup with two monitors, one displaying a white screen with a black bar at the bottom, and the other showing a dark screen. A wooden sign with the word "ANOPSIA" is visible on the shelf above the monitors. The desk is cluttered with various items, including a white cup, a black mouse, and a mouse pad. The lighting in the room is dim, with purple LED lights illuminating the scene, creating a tech-oriented atmosphere.

Here's my SeinSmart Genmitsu 4030 ProxerXL in its new robot box. I've tried to tighten up the spindle and tool a bit for another pass.

I plan to buy longer hex wrenches tomorrow to get more leverage.

This is working on 3/8 in / ~9.5 mm thick 6061 aluminum at 100 mm / minute with a 3.175 mm flat tool at 0.5 mm depth per pass with a custom gcode generator.

#cnc #aluminum #router #maker #cncrouter #cncaluminum #foss #fosh #genmitsu #seinsmart #proverxl #proverxl4030

A workspace with a CNC machine enclosed in a transparent protective casing. The machine is blue and silver, with a label reading "Genmitsu." It is mounted on a workbench, surrounded by various tools and equipment. On the left side of the image, there is a can of WD-40 lubricant, a black electronic device, and a digital display. The background includes wooden beams and a cardboard box with the word "sigma" visible. The workspace appears cluttered with tools and cables, indicating an active work environment.

Getting my aluminum router back up and running.

#cnc #aluminum #router #maker #cncrouter #cncaluminum #foss #fosh #genmitsu #seinsmart #proverxl #proverxl4030

a close-up of a metallic L-shaped corner bracket being held by a hand. The bracket has a shiny, silver finish with visible layer lines, indicating it was CNC machined. It features four bolts. The background is blurred, but it appears to be a workspace with a keyboard, a mouse, and some decorative items, including a sign with the letters "ANOPSIA." The lighting is dim with a purple hue, suggesting the presence of LED lights.

I published a parametric fume extraction adapter on Printables for the Genmitsu 3018 router. It can be customized using the CadQuery CAD scripting API. #3DPrinting #Genmitsu #Makerspace #CadQuery #ParametricCAD

https://www.printables.com/model/787157-fan-and-duct-adapter-for-genmitsu-3018-cnc-router-

#genmitsu 4030 is so much bigger than 3020, for 10 cm extra on each axis ! #cnc #Maker #Hobbyist #CNCMachine #Woodworking #Craftsmanship #Tech #Innovation #CNCBuild #Robotics #MakersGonnaMake #EngineeringDesign #CNCProject #WoodworkingTools #TechDIY

A wide-angle view of a CNC router with a spindle motor, control electronics, and a partially constructed drag chain. The bench holds various electronic components and tools, indicative of an active project in progress.

Overhead view of a CNC machine with blue stepper motors, a control board, and wiring. A spindle with a dust collection attachment is at the center, set against a backdrop of a cluttered workshop bench with tools and materials.

This was suppose to be a short on my new youtube channel , but I posted it as a regular teaser video.
Love the 3020Pro #SainSmart #Genmitsu #CNC , really good machine. I think I might outgrow it soon tho :)

Anyone interested in a full tutorial ?
Or even a review of this machine and comparison to 3018 ?

https://www.youtube.com/watch?v=j-TRE-cd0vQ

I've never done a video like this before, so do let me know please.
#freecad #FreeSoftware

#engraving #coins #makerspace #genmitsu #sainsmart 3020 and 60 deg v bit.

I love the way the large, frameless #CNC-cut projection panels have turned out, made by the American University, Cairo.
We made small samples on a #Sainsmart #Genmitsu machine in wood, cardboard, aluminium, acrylic and home-pressed HDPE plastic, and in cardboard on a #Cricut.
